1. Project Background
Global industrial motor, new energy vehicle and UAV manufacturing sectors are raising stricter requirements for motor spare parts: core components including motor housings, shafts, end covers and stator brackets demand ultra-high concentricity, dynamic balance performance and batch consistency. Traditional general machining processes cannot meet the customized demands of multi-variety, small-batch and high-precision motor parts, which easily leads to unstable assembly accuracy, shortened motor service life and high production scrap rate.
Leveraging the existing 24/7 unmanned CNC workshop foundation in Xinjingchuang Technology’s Dongguan base, this solution targets full-scenario customized production for motor spare parts and components, and builds a full-process closed-loop intelligent manufacturing system covering demand docking, process customization, precision machining and strict quality inspection. It fully matches the delivery requirements of global industrial motor clients for high precision, short lead time and stable quality.
2. Core Solution Objectives
This customized CNC machining solution sets 4 quantifiable delivery targets within 12 months:
. Stabilize the machining tolerance of core motor spare parts within ±0.01mm, and control the coaxiality of motor shaft and housing below 0.008mm;
. Raise the batch qualification rate of customized motor components to over 99.3%, and reduce the client assembly rework rate to less than 0.5%;
. Shorten the production lead time of custom motor spare parts from 7 working days to 3 working days, and support urgent prototype sample delivery within 48 hours;
. Achieve 95% coverage of automatic inspection for motor key dimensions, and realize full traceability of all component machining data.
3. Key Customized Machining Measures
First, develop exclusive process packages for different motor components. For motor shafts and other rotating parts with strict dynamic balance requirements, we configure CNC lathes equipped with online detection systems, which can monitor roundness and runout data in real time and dynamically adjust cutting parameters. For lightweight new energy motor housings made of 6061/7075 aluminum alloy, we adopt high-speed spindle above 15000rpm, special thin-wall clamping fixtures and stress-relief processes, which effectively control the deformation of 2-5mm thin-wall parts within 0.02mm.
Second, build a dedicated motor component CNC production unit. Deploy 5-axis linkage and turn-mill composite machining equipment to realize one-time clamping for complex curved surface motor parts, which avoids accuracy accumulation error caused by repeated clamping. We support full material coverage including aluminum alloy, stainless steel, titanium alloy, copper and engineering plastics, and can quickly switch processes for different batches of motor spare parts.
Third, integrate the whole process with the unmanned workshop scheduling system. After the client uploads 3D drawings and 2D tolerance specifications, the system automatically completes DFM manufacturability analysis, generates the optimal tool path and machining schedule, and directly sends instructions to the CNC equipment. The whole process from raw material incoming, automatic loading and unloading, machining to finished product inspection does not require manual intervention on site.
Fourth, establish a special quality control system for motor components. Equip each station with a 3D visual positioning module and high-precision on-line measuring instrument, and automatically archive all dimension inspection data, machining parameter records and material certification reports. Clients can check the full production progress and quality data of their orders in real time through the cloud platform.
4. Implementation Phases & Benefit Delivery
The solution is rolled out in 3 phases:
. Phase 1 (0-3 months): Complete the process verification of 8 typical motor spare parts, and finish the debugging of the dedicated CNC production unit;
.Phase 2 (3-8 months): Realize full coverage of automatic machining for 16 categories of motor components, and connect the quality inspection data to the client traceability platform;
. Phase 3 (8-12 months): Form a standardized customized machining system for motor spare parts, and support stable mass delivery of 100,000+ pieces per month.
After implementation, the overall equipment efficiency of the motor component production line will reach over 93%, the annual comprehensive production cost will be reduced by more than 35%, and Xinjingchuang Technology will be built into a high-standard customized CNC machining base for global high-end motor manufacturers in Dongguan, Guangdong.
